- Description
- Specifications
| Standards | IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX IEEE 802.3ab 1000Base-T IEEE 802.3x Flow Control IEEE 802.3az Energy Efficient Ethernet |
| Device Interface | 24 x Gigabit Ports 2 x SFP slots LED indicators |
| Network Media | Ethernet: Cat. 5 up to 100 m Fast Ethernet: Cat. 5 and 5e up to 100 m Gigabit Ethernet: Cat. 5e and 6 up to 100 m |
| Data Transfer Rate | Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex) Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex) Gigabit Ethernet: 1000 Mbps (full duplex) |
| Protocol / Topology | CSMA / CD, Star |
| Switch Fabric | 48 Gbps switching capacity |
| Interface | 24 x 10/100/1000 Mbps Auto-MDIX RJ-45 ports |
| Jumbo Frame Support | Up to 10 KB |
| Management | HTTP Web based GUI Virtual Cable Test Mirroring |
| Link Aggregation | Static Link Aggregation |
| VLAN | Multiple management VLAN assignment 802.1Q Tagged VLAN Up to 256 VLAN groups, ID Range 1-4094 |
| QoS | Port Based Rate Limit |
| Multicast | IGMP Snooping v1, v2, v3 (per VLAN) Up to 256 multicast entries |
| Security | Loopback Detection Storm Control Denial of Service (DoS) |
| ACL IPv4 | IP |
| Diagnostic LED | Power, 10/100 Mbps Link / ACT, 1000 Mbps Link / ACT, PoE |
| Special Features | Fanless Design IPv6 802.3az power saving Rack mountable |
| Power | 100~240 VAC, 50/60 Hz Internal universal switching power |
| Operating Temperature | 0 - 50 ¡ãC (32 - 122 ¡ãF) |
| Operating Humidity | Max. 90% non-condensing |
| Dimensions | 440(L) x 200(W) x 44(H)mm |
