SP2400G-2SFP with 24x 10/100/1000Mbps PoE Ports, 2x 10/100/1000Mbps SFP Ports, all RJ45 ports support auto-negotiation, auto MDI/MDIX; SP2400G-2SFP with maximum 440W power supply, fully work with IEEE 802.3af/at standard PoE PD equipment, simply plug and play, for high density PD equipment environment, such as hotel, campus, industry zone, shopping mall, to guarantee the important data transmission without any delay, it deal with flow classification based on different environment and application.
| Standards | IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX IEEE 802.3ab 1000Base-T IEEE 802.3x Flow Control IEEE 802.3af IEEE 802.3at IEEE 802.3az Energy Efficient Ethernet |
| Device Interface | 24 x Gigabit Ports 2 x SFP slots LED indicators |
| Network Media | Ethernet: Cat. 5 up to 100 m Fast Ethernet: Cat. 5 and 5e up to 100 m Gigabit Ethernet: Cat. 5e and 6 up to 100 m |
| Data Transfer Rate | Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex) Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex) Gigabit Ethernet: 1000 Mbps (full duplex) |
| Protocol / Topology | CSMA / CD, Star |
| Switch Fabric | 48 Gbps switching capacity |
| Interface | 24 x 10/100/1000 Mbps Auto-MDIX RJ-45 ports |
| Jumbo Frame Support | Up to 10 KB |
| Management | HTTP Web based GUI Virtual Cable Test Mirroring |
| Link Aggregation | Static Link Aggregation |
| VLAN | Multiple management VLAN assignment 802.1Q Tagged VLAN Up to 256 VLAN groups, ID Range 1-4094 |
| QoS | Port Based Rate Limit |
| Multicast | IGMP Snooping v1, v2, v3 (per VLAN) Up to 256 multicast entries |
| Security | Loopback Detection Storm Control Denial of Service (DoS) |
| ACL IPv4 | IP |
| Diagnostic LED | Power, 10/100 Mbps Link / ACT, 1000 Mbps Link / ACT, PoE |
| Special Features | Fanless Design IPv6 802.3az power saving Rack mountable |
| Power | 100~240 VAC, 50/60 Hz Internal universal switching power |
| Operating Temperature | 0 - 50 ¡ãC (32 - 122 ¡ãF) |
| Operating Humidity | Max. 90% non-condensing |
| Dimensions | 440(L) x 200(W) x 44(H)mm |
